Upgrade Equallogic MEM to v1.1.0
Comments (0) The reason I choosed to upgrade MEM first is becuase in the release note of MEM 1.1.0, it is said the minimum EQL FW should be v4.3.7 (which I’m on v5.0.2), but FW v5.2.2 states clearly that it only supports MEM 1.1.0, so I need to upgrade MEM first before I upgrade my EQL firmware to v5.2.2 and add HIT/VE v3.1.1 later.
1. Remember to put your ESX host to Maintenance Mode FIRST!!!
2. Use the MEM installation script as I found this is the most simple method, open vSphere CLI
C:\>setup.pl –install –server=xxx.xxx.xxx.xxx
You must provide the username and password for the server.
Enter username: root
Enter password:
Upgrading from existing Dell EqualLogic Multipathing Extension Module installed:
DELL-eql-mem-1.0.0.130413
Defaulting to offline bundle ‘C:\dell-eql-mem-esx4-1.1.0.222691.zip’
The install operation may take several minutes. Please do not interrupt it.
Upgrade install was successful.
You must reboot before the new version of the Dell EqualLogic Multipathing Exten
sion Module is active.
3. Remember to Reboot it as well if your host is ESX 4.1
4. Check if the MEM is installed correctly, found out MEM setting has been set to default, so need to change it again to its maximum power to ultilize all 4 paths. (ie, volumesessions=12, membersessions=4)
C:\>setup.pl –query –server=xxx.xxx.xxx.xxx
You must provide the username and password for the server.
Enter username: root
Enter password:
Found Dell EqualLogic Multipathing Extension Module installed: DELL-eql-mem-esx4
-1.1.0.222691
Default PSP for EqualLogic devices is DELL_PSP_EQL_ROUTED.
Active PSP for naa.6090a078e03b90b5b1d654e6e700d0fc is DELL_PSP_EQL_ROUTED.
Active PSP for naa.6090a078c06ba23424c914a0f1889d68 is DELL_PSP_EQL_ROUTED.
Active PSP for naa.6090a078e03bd0aad3cc34ade700500f is DELL_PSP_EQL_ROUTED.
Active PSP for naa.6090a078e03b80201dcbe4a5e70010ee is DELL_PSP_EQL_ROUTED.
Active PSP for naa.6090a078e03b40e895cc74abe70000fd is DELL_PSP_EQL_ROUTED.
Found the following VMkernel ports bound for use by iSCSI multipathing: vmk2 vmk
3 vmk4 vmk5
C:\>setup.pl –listparam –server=xx.xxx.xxx.xxx
You must provide the username and password for the server.
Enter username: root
Enter password:
Parameter Name Value Max Min Description
————– —– — — ———–
TotalSessions 512 1024 64 Max number of sessions per host.
VolumeSessions 6 12 1 Max number of sessions per volume.
MemberSessions 2 4 1 Max number of sessions per member per volume.
MinAdapterSpeed 1000 10000 10 Minimum adapter speed for iSCSI multipathing.
C:\>setup.pl –setparam –name=VolumeSessions –value=12 –server=xxx.xxx.xxx.xxx
C:\>setup.pl –setparam –name=MemberSessions –value=4 –server=xxx.xxx.xxx.xxx
* Make sure you have 4 NICs for iSCSI before setting MemberSessions to 4 or you will see high TCP Retransmit.
5. Double check the storage path in vCenter to make sure MEM is the default PSP and all 4 paths are Active.
